Simrad GC80 User Manual

TERMINAL LAYOUT
20221537 / D 97
PIN NO NAME DETAILS
28 5R24-
Serial repeater power supply, -24V DC
29 5R24+ Serial repeater power supply, +24V DC
30 6TX+
31 6TX-
Serial signal output (IEC61162-1 ed.2/-2)
32 6TSC Serial signal common
33 6R24- Serial repeater power supply, -24V DC
34 6R24+ Serial repeater power supply, +24V DC
35 7TX+
36 7TX-
Serial signal output (IEC61162-1 ed.2/-2)
37 7TSC Serial signal common
38 7R24- Serial repeater power supply, -24V DC
39 7R24+ Serial repeater power supply, +24V DC
40 8TX+
41 8TX-
Serial signal output (IEC61162-1 ed.2/-2)
42 8TSC Serial signal common
43 8R24- Serial repeater power supply, -24V DC
44 8R24+ Serial repeater power supply, +24V DC
45 ST41
46 ST42
47 ST43
Step signal (open drain signal)
48 OCACN1
49 ST1/OPRX+
50 ST2/OPRX-
51 ST3/OPSC
52 OPMC+
53 OPMC-
54 GTX+
55 GXT-
56 GTSC
Not used
57 ST11
58 ST12
59 ST13
Step signal (open drain signal)
60 ST14 -24V DC for step signal output 1
61 ST15 +24V DC for step signal output 1

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
