Simrad GC80 User Manual

Simrad GC80/GC85 Dual Gyro Compass
102 20221537 / D
11.1 General
7 different boards in the Dual control unit have jumpers and/or
dip switches that is used for configuring the GC80/85 system.
Only a few of these jumpers/dip switches are used in installation
and pre-running procedure for the gyro compass. Refer Power
supply, page 47, and Dip-switch and jumper settings, page 48.
The following pages include drawings showing location of all
jumpers and/or dip switches, together with a short description
for the different settings.
SCC
BOARD 1
GTERM
BOARD
SCOIF
BOARD
GPOWER
BOARD 1
GPOWER
BOARD 2
SCC
BOARD 2

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
