Simrad GC80 User Manual

Simrad GC80/GC85 Dual Gyro Compass
38 20221537 / D
4.8 Replacing the Fuses
WARNING Before a fuse is replaced, disconnect the
respective power for the damaged fuse.
Use the procedures described in the following pages when
replacing the fuses.
Master Compass
Fuse F1 is located inside the fuse holder in the front of the
Master compass.
1. Open the fuse holder by pressing and turning the fuse
holder edge counter-clockwise with a screw driver.
2. Replace fuse F1, and close the holder by turning it
clockwise.
F1 (12A)

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
