Simrad GC80/GC85 Dual Gyro Compass
104 20221537 / D
11.3 GTERM board
TB4
TB3
TB1
J9
J4
J5
J6
J8
J7
J2
J1
TB2
J11 J12
J13
J50
Jumper settings on GTERM board
JUMPER DEFAULT FUNCTION DESCRIPTION
TB3 – TB4 - Gyro system
Open = Two gyro systems
Short = One gyro system
