Simrad GC80 User Manual

OPERATION
20221537 / D 19
Display state Display Description
afpm
4
th
press on
DISP button
- Rate of turn in °/min
- Rate of turn indication
afpm
5
th
press on
DISP button
- Error codes (up to 4)
- Error indication
afpm
6
th
press on
DISP button
Normal operation
dvol
buq
- True output bearing
- Active compass
Displaying settings with external sensor
connected
Display state Display Description
Normal operation
dvol
buq
or
dvol
buq
- True output bearing
- Active compass
The compass indication equals the sensor
selected as active compass (gyro or
external)
afpm
1
st
press on
DISP button
or
- Bearing
- Passive compass

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
