Simrad GC80 User Manual

DIP SWITCH SETTINGS
20221537 / D 119
DIP switch settings on PCC board
SWITCH DEFAULT FUNCTION DESCRIPTION
S1-1 OFF HDM function OFF = Yes, ON =No
S1-2 OFF OCA function OFF = NO, ON =Yes
SW1-3 OFF
SW1-4 OFF
No external sensor
connected
SW1-3 OFF
S1-3 OFF
SW1-4 ON
Magnetic system connected
(back-up)
SW1-3 ON
SW1-4 OFF
External sensor connected
SW1-3 ON
S1-4 OFF
External sensor
configuration
SW1-4 ON
External sensor connected
(back-up)
S1-5 ON Input of steering mode
information
S1-6 ON SIMRAD / Tokimec ON = Simrad, OFF = Tokimec
S1-7 OFF
S1-8 OFF
Not used
Jumper settings on PCC board
JUMPER DEFAULT FUNCTION DESCRIPTION
J4 Open CPU reset
This jumper is used when
resetting "CPU."
J5
Short Software installation
Open: Software is installed in
SCCpwb
NOTE:
A damage will be given
to a circuit if software is
installed while this
jumper has been short.
J6 Open "Power supply" switch
Short: Power "ON." (Power
supply switch" pass.)

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
