Simrad GC80 User Manual

Simrad GC80/GC85 Dual Gyro Compass
110 20221537 / D
Jumper settings on SCOIF board
JUMPER DEFAULT FUNCTION DESCRIPTION
J15 3-4 short
Output port: GTERM board, TB2:
"3TX"
1-2 short = EC61162-2 or
TOKIMEC version
3-4 short = IEC61162-1 ed.2
(ref. page 4)
NOTE
: Never use both jumpers
at the same time!
J16 3-4 short
Output port: GTERM board, TB2:
"4TX"
1-2 short = EC-61162-2 or
TOKIMEC version
3-4 short = IEC-61162-1 ed.2
(ref. page 4)
NOTE
: Never use both jumpers
at the same time!
J17 3-4 short
Serial signal output
setting
Output port: GTERM board, TB2:
"5TX"
1-2 short = EC61162-2 or
TOKIMEC version
3-4 short = IEC61162-1 ed.2
(ref. page 4)
NOTE
: Never use both jumpers
at the same time!
J18 Short
J19 Short
Type setup
Short: Standard
Open: With external sensor
connected (type M or E)

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
