Simrad GC80 User Manual

Simrad GC80/GC85 Dual Gyro Compass
78 20221537 / D
7.4 Output specification
Serial output signal 1
Circuits:...................................................................10
Electrical: ..................................................RS422/485
Baud rate:
GC80: ........................................... 4800/38400 bps
GC85 ..................................................... 38400 bps
Data bits: ............................................................8 bits
Parity:................................................................. None
Stop bits: ...................................................................1
Transmit freq.:
GC80 ............................................... 1, 5, 10, 50Hz
GC85: .............................................. 1, 5, 10, 50Hz
Output format:
Data no.1
$ HEHDT,xxx.x,T*hh<CR><LF>
Data no.2
$ HEROT,-xxx.xx,A*hh<CR><LF>
Data no.3
$ PCICM,HEALM,xxxx,x,xx*hh<CR><LF>
Serial output signal 2 *1
Circuits:...................................................................10
Electrical: ..................................................RS422/485
Baud rate:
GC80: ...................................................... 4800 bps
GC85 ..................................................... 38400 bps
Data bits: ............................................................8 bits
Parity:................................................................. None
Stop bits: ...................................................................1
Transmit freq.:
GC80 ............................................... 1, 5, 10, 50Hz
GC85: .............................................. 1, 5, 10, 50Hz
Output format:
Data no.1
$ HEHDT,xxx.x,T*hh<CR><LF>
Data no.2
$ PTICM,--xxxx,x,xx,*hh<CR><LF>
When Gyro
is selected
When
External
heading
sensor is
selected

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
