Simrad GC80 User Manual

TECHNICAL SPECIFICATION
20221537 / D 77
7.3 Input specification
Serial input signal (GPS)
Circuits:.....................................................................1
Electrical: .............. RS422/MNEA0183/Current loop
Baud rate:..................................................... 4800 bps
Data bits: ............................................................8 bits
Parity:................................................................. None
Stop bits: ...................................................................1
Freq.: .............................................................. 1 – 5Hz
Input format:
$--GGA,x,xxxx.xx,N,xx.x,E,x,~*hh<CR><LF>
$--GLL,xxxx.xx
,N,xxxx.xx,E,*hh<CR><LF>
$--VTG,xx
,T,xx,M,xx.x,N,xx,K*hh<CR><LF>
Serial input signal (External heading)
Circuits:.....................................................................1
Electrical: ....................................RS422/NMEA0183
Baud rate:..........................................4800/38400 bps
Data bits: ............................................................8 bits
Parity:................................................................. None
Stop bits: ...................................................................1
Freq.: ...........................................1 - 50Hz/20 – 50Hz
Input format:
$--HDT,xxx.x*hh<CR><LF>
$--HDG,xxx.x
*hh<CR><LF>
Serial input signal (LOG)
Circuits:.....................................................................1
Electrical: ....................................RS422/NMEA0183
Baud rate:..................................................... 4800 bps
Data bits: ............................................................8 bits
Parity:................................................................. None
Stop bits: ...................................................................1
Transmit freq.: ..............................................1 - 50Hz
Input format:
$--VBW,x.x,x.x,A,~*hh<CR><LF>
PULSE signal (LOG)
Circuits:.....................................................................1
Electrical: .................... 200/400 p.p.n.m., dry contact

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
