Simrad GC80/GC85 Dual Gyro Compass
100 20221537 / D
PIN NO NAME DETAILS
51 OCACN1
52 OCANC2
Off course alarm contact output (Not used)
53 MALCN1
54 MALCN2
Alarm contact for selected gyro
55 MRNCN1
56 MRNCN2
Running contact for selected gyro
57 G1-2TX+
58 G1-2TX-
No 1 GYRO Serial signal output
(IEC61162-1 ed.2/-2
59 G1-2SC Serial signal common
60 G2-2TX+
61 G2-2TX-
No 2 GYRO Serial signal output
(IEC61162-1 ed.2/-2
62 G2-2SC Serial signal common
63 24MN+
64 24MN-
Not used
