Simrad GC80 User Manual

Simrad GC80/GC85 Dual Gyro Compass
108 20221537 / D
JUMPER DEFAULT FUNCTION DESCRIPTION
J9 3-4 short Alarm contact setting
Output port: GTERM board, TB1
"ALCN"
1-2 Short = Alarm "CLOSES",
Normal "OPEN"
3-4 Short = Alarm "OPEN",
Normal "CLOSES"
NOTE
: Never use both
jumpers at the same
time!
J10 3-4 short Running contact setting
Output port: GTERM board, TB1
"RNCN"
1-2 Short = Alarm "CLOSES",
Normal "OPEN"
3-4 Short = Alarm "OPEN",
Normal "CLOSES"
NOTE
: Never use both
jumpers at the same
time!

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
