Simrad GC80 User Manual

DIP SWITCH SETTINGS
20221537 / D 117
JUMPER DEFAULT FUNCTION DESCRIPTION
J46 * 1-2 short
Output port: GTERM board. TB2:
"ST1/OPRX+"
1-2 short = The step signal for
"Step signal type
repeater" is output
(ST1).
3-4 short = Serial signal
receive.(OPTION)
(OPRX+)
NOTE:
Never use both
jumpers at the same
time!
J47 * 1-2 short
Output port: GTERM board. TB2:
"ST2/OPRX-"
1-2 short = The step signal for
"Step signal type
repeater" is output
(ST2).
3-4 short = Serial signal
receive.(OPTION)
(OPRX-)
NOTE:
Never use both
jumpers at the same
time!
J48 * 1-2 short
Output port setup for
GTERM board
Output port: GTERM board. TB2:
"ST2/OPRXC"
1-2 short = The step signal for
"Step signal type
repeater" is output
(ST3).
3-4 short = Serial signal
receive.(OPTION)
(OPRXC)
NOTE:
Never use both
jumpers at the same
time!
*: All three jumpers should be changed simultaneously

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
