Simrad GC80 User Manual

INSTALLATION
20221537 / D 49
J1
J4
J3
J2
6
1ON
8
1ON
SW4
8
1ON
SW3
SW2
SW1
ON
8
1
DS1
DS2
DS3
DS4
DS5
DS6
12
12
12
56
12
34
1
3
2
4
1
3
2
4
J5
J6
J7
J8
J9
J10
U1
U52
BT1
SCC board
GC80 system GC85 system
OFF
S1
1
8
S1
8
1
ON
All outputs are selectable for 1, 5, 10 or 50Hz.
Refer dip switch and jumper settings on page 101 onwards.
Note! A GC85 system is recommended to be set for 50Hz output!
SCC BOARD NO.1
FOR MASTER
COMPASS NO.1
(LOCATED
UNDERNEATH THE
GTERM BOARD)
SW1
SCC BOARD NO.2
FOR MASTER
COMPASS NO.2
SCIOF BOARD

Simrad GC80 Specifications

General

Type	Gyro Compass
Power Supply	24 V DC
Operating Temperature	-15°C to +55°C
Heading Resolution	0.01°
Heading Repeatability	±0.1°
IP Rating	IP66
Storage Temperature	+70°C
Interfaces	NMEA 0183
Humidity	95% non-condensing
