Introduction
The MK 6.0 Radar Interface box is a separate device intended to convert analog radar signal
to raw data and send it using the Ethernet to the Extractor/Tracker application operating on a
PC.
The device has two basic configurations: Slave and Master.
A Slave configured MK 6.0 Radar Interface box receives video and synchronization signals
from the vessel radar, whilst a Master configured MK 6.0 Radar Interface box provides
additional radar control functionality. The Master configuration is available for the Litton/
Sperry radar only.
Ú
Note: The Sensor Monitor application is installed with an ECDIS900 or Radar2014 application.
1
Introduction | MK 6.0 Installation Manual
5
