Sinterit LISA X User Manual | 13
3.4 PRINTER DESCRIPTION
1
LID HANDLE
17
INFRARED BULB
16
RECOATER
15
RECOATER CORD
14
RECOATER DRIVE UNIT CORD
12
PRINT BED
11
RESET BUTTON
10
USB PORT
13
RECOATER GUIDE BAR
2
SPLIT PIN
3
HEATING MODULE
4
PRINTER LID
6
EMERGENCY STOP
PUSHBUTTON (E-STOP)
8
DOOR
9
OVERFLOW
CONTAINER
7
FEED BED
5
SCREEN
Fig. 3.1 Front view of the printer, heating module and overow container.
18
PYROMETER
WINDOW
Fig. 3.2 View of the print chamber.
19
LID HINGES
20
INERT GAS CONTROL
SYSTEM
Fig. 3.3 View of the left side of the printer.
