Sinterit LISA X User Manual | 18
IMPORTANT!
Do not use isopropyl alcohol to clean the laser protective glass.
5. Wipe the glass again on both sides with a dry cotton cloth.
6. Slide the metal tabs of the laser protective glass into the mounting brackets below the laser module.
7. Lock the laser protective glass in place by mounting and tightening the two quick release nuts.
8. Lift the heating module.
9. Reinsert the heating module safety pin.
LASER PROTECTIVE GLASS
%
1
5
6 7
2 3
4
Fig. 5.5 Mounting the laser protective glass.
