SKF IMx-1 - Signal Processing; Interfaces

PRODUCT SPECIFICATIONS
SKF Enlight Collect IMx-1 System
User Manual
Revision F
83 (101)
5.1.4 Signal processing
Table 7 Wireless sensor signal processing specifications
Model designation
IMx-1
Enveloper 3
0 to 1 kHz
Source
0.5 to 10 kHz
‘E3’ measurement
True pk-pk
Acceleration
10 Hz to 10 kHz
‘A’ measurement
True pk-pk
Velocity
10 to 1000 Hz
‘V’ measurement
RMS
All vibration
TWF:1 each A, V, Env.
TWF samples
Up to 16 384 (currently 400, 800 or 1600-line
FFT in @ptitude Observer)
Temperature
Latest and 256 last saved values
Alarm thresholds
Configurable Alert & Danger
Sources
All overall measurements
Measurement alarm thresholds Vibration
0 to greater than IMx-1 dynamic range
Temperature (maximum configurable range)
–49 to 205
0
C (–56.2 to +401
0
F)
Self-diagnostics
Yes
5.1.5 Interfaces
Table 8 Wireless sensor interface specifications
Model designation
IMx-1
WPAN IEEE 802.15.1
Yes
Range
3 m (10 ft) typical
Proximity IEC 14443
Yes
Range
< 20 cm
Mesh network
Yes
Maximum range
10 to 20 m (33 to 66 ft) typical node–node
in an industrial environment
Interface to gateway
Mesh network as above
Interface to app
Proximity and WPAN
(In app this uses NFC and Bluetooth)
OTA FW update
Yes
Notes:
WPAN IEEE 802.15.1: Bluetooth SIG certification is pending.
OTA: Over The Air device firmware updates
