PRODUCT SPECIFICATIONS
Enlight Collect gateway specifications
88 (101)
SKF Enlight Collect IMx-1 System
User Manual
Revision Letter A
5.2 Enlight Collect gateway specifications
5.2.1 Environmental and physical
Table 9 Gateway environmental specifications
Housing material
ASA+PC-FR Flame Retardant
Acrylonitrile Styrene Acrylate + Polycarbonate
Flammability
UL 94 V-0
Dimensions
220 x 220 x 50.5 mm (8.66 x 8.66 x 1.99 in.)
Mounting
4-point
Weight
1.2 kg
IP rating
IP65
User connections
Four connectors: refer Figure 2
Operating
–20 to +60 °C (–4 to +140 °F)
Storage
–40 to +60 °C (–40 to +140 °F)
Humidity
Maximum 95% relative non-condensing
Altitude
Maximum 5 000 m (16,404 ft.)
Hazardous area rating
Safe area use only (ATEX/IECEx zone 2 and NA NEC Zone 2/
Class 1 Div 2 approval option pending)
NA NEC pending approval
5.2.2 Power
Table 10 Gateway power specifications
Parameter
Specification
Powering options
Industrial range 24 V DC or PoE
24V input voltage range
9 to 36 V DC
Power over Ethernet
IEEE 802.3af: nominal voltage 48 V, 13 W maximum
PoE is available at the Ethernet 1 connection
Power consumption
7.5 W maximum
Other protection
Reversed supply, transient voltage protection
Redundancy
No, unless external provision is made
Notes:
The gateway circuitry is isolated from the supply connections.
