SKF MKU Series Assembly Instructions

16
Table 4
Parameters of the IG38-30-I
Designation
Default
Setting via
Setting range
Interval time
1 min
Rotary switch
1 – 2048 min (in
binary
increments)
Monitoring
time
60 sec
Not adjustable
+ 3000 min
Delay time
15 sec
Not adjustable
+ 4000 min
+ 5000 min
Control unit: IZ38-30-I
Description: The IG38-30-I is used as a pulse pulse counter
Functions:
• Adjustable interval time
• Pump cycle time limitation
• Pressure build-up monitoring
• Fill level monitoring (NC contact)
Table 5
Parameters of the IZ38-30-I
Designation
Default
Setting via
Setting range
Interval time
1 pulses
Rotary switch
1 – 2048 pulses
(in binary
increments)
Monitoring
time
60 sec
Not adjustable
+ 3000 pulses
Delay time
15 sec
Not adjustable
+ 4000 pulses
+ 5000 pulses
Control unit: IGZ36-20-S6-I
Description: The IGZ36-20-S6-I device can be used as a pulse
generator (operating mode B) and a pulse counter (operating
mode D).
Functions:
• Adjustable interval time
• Adjustable pump delay time
• Adjustable monitoring time
• Pump cycle time limitation
• Pressure build-up monitoring
• Pressure reduction monitoring
• Fill level monitoring (NC contact)
Table 6
IGZ36-20-S6-I parameters
Designation
Abbreviation
Default
Setting range
Operating
mode
BA
B
B (pulse
generator)
D (pulse counter)
Interval time
TP
10 min
01 E 00 - 99 E
04 (BA B)
min
01 E 00
- 99 E
04 (BA D) pulses
Monitoring
time
TU
60 sec
01 E 00 – 10 E
01 sec
Delay time
TN
15 sec
01 E 00 – 30 E
00 sec
Control unit: IG54-20-S4-I
Description: The IG54-20-S4-I device can only be used as a
pulse generator (operating mode B).
Functions:
• Adjustable interval time
• Adjustable number of prelubrication cycles
• Adjustable pump delay time
• Pump cycle time limitation
• Oil pressure monitoring
• Air pressure monitoring
• Fill level monitoring (NC contact)
• Power-failure memory (EEPROM)
• Additional output d3 for compressed-air valve
Table 7
IG54-20-S4-I parameters
Designation
Abbreviation
Default
Setting range
Operating
mode
BA
B
Not adjustable
Interval time
TP
10 min
01 E 00 - 99 E
00 min
Monitoring
time
TU
60 sec
Not adjustable
Delay time
TN
5 sec
00 E 00 – 99 E
00 sec
Prelubrication
cycles
VZ
10 sec
00 E 00 – 99 E
00 sec
