SKF TMEB 2 Belt alignment tool

3.4 Determining the type of misalignment

The laser line emitted from the laser unit will now appear on the

receiver unit. The pattern will vary depending on the type of

misalignment, as shown in figure 5, 6, 7 and 8.

Fig. 5. Display of vertical angle

misalignment

Fig. 6. Display of horizontal

angle misalignment

Fig. 7. Display of parallel

misalignment

Fig. 8. Display of all three

misalignments combined
