Skyjack SJ46 AJ+ Service Manual

58
229042ABA SJ46 AJ+, SJ46 AJ, SJ51 AJ
Section 3 – System Component Identification and Schematics Hydraulic Parts List
Index
No.
Skyjack
Part No.
Description
CB5 149488 VALVE, Counterbalance (Riser Down)
CB6 149488 VALVE, Counterbalance (Riser Down)
CB7 149228 VALVE, Counterbalance (Platform Level, Slave)
CB8 149228 VALVE, Counterbalance (Platform Level, Slave)
CB9 152326 VALVE, Counterbalance (Boom Lift)
CB10 149228 VALVE, Counterbalance (Fly Boom Extend)
CB11 141453 VALVE, Counterbalance (Fly Boom Retract)
CB12 149372 VALVE, Counterbalance (Jib)
CB13 149372 VALVE, Counterbalance (Jib)
CB14 141399 VALVE, Counterbalance (Rotary Actuator)
CB15 141399 VALVE, Counterbalance (Rotary Actuator)
CP1 231437 PLUG, Cavity
CV1 N/A VALVE, Check (EPU)
CV2 171413 VALVE, Check (Brake Manifold)
CV3 166064 VALVE, Check (Main Control)
CV4 159817 VALVE, Check (Double, Piloted, Platform Level)
CV5 163183 VALVE, Check (Riser)
CV6 163182 VALVE, Check (Riser)
CV7 166067 VALVE, Check (LS)
CV8 166067 VALVE, Check (LS)
CV9 166067 VALVE, Check (LS)
CV10 166067 VALVE, Check (LS)
CV11 166067 VALVE, Check (LS)
CV12 166067 VALVE, Check (LS)
CV13 N/A VALVE, Check (Generator 3.5kW)
CV14 N/A VALVE, Check (Generator 12kW)
CV15 N/A VALVE, Check (Generator 12kW)
CV16 168243 VALVE, Check (2 SPD)
DSV1 166059 VALVE, System Load Sense (Differential Sensing Valves)
DSV2 166062 VALVE, Differential Sensing (Boom Rotate)
DSV3 166063 VALVE, Differential Sensing (Riser)
DSV4 166063 VALVE, Differential Sensing (Main Lift)
DSV5 166062 VALVE, Differential Sensing (Jib/Platform Rotate)
EPU 160923 PUMP, Emergency Power Unit
F1 161932 FILTER, High Pressure
F2 161934 FILTER, Return
M1 161964 MOTOR, Drive
M2 N/A MOTOR, Swing
M3 N/A MOTOR, Generator - 3.5kW Generator Option
M4 N/A MOTOR, Generator - 12kW Generator Option
MB1 162495 MANIFOLD, Main
MB2 168642 MANIFOLD, Brake
MB3 231501 MANIFOLD, Jib
MB4 169526 MANIFOLD, Generator 12 kW
MB5 169390 MANIFOLD, Generator 3.5 kW
MB7 208620 MANIFOLD, Load Circuit
3.4 Hydraulic Parts List
