Skyjack SJ46 AJ+ Service Manual

59
229042ABASJ46 AJ+, SJ46 AJ, SJ51 AJ
Hydraulic Parts List Section 3 – System Component Identification and Schematics
Index
No.
Skyjack
Part No.
Description
OC1 160800 COOLER, Oil (Oil Cooler Option)
OR1 167353 ORIFICE, Main Control (Platform Rotate)
OR2 167352 ORIFICE, Main Control (Jib)
OR3 166056 ORIFICE, Main Control (Boom Extend)
OR4 166057 ORIFICE, Main Control (Platform Level)
OR5 171420 ORIFICE, Brake Manifold (Loop Flush)
OR6 163710 ORIFICE, Riser Down (0.067”)
OR7 195033 VALVE, Needle (Load Circuit)
P1/P1A 170599
PUMP, Drive
- Deutz D2.9L, Deutz D2011, Kubota, GM
P1/P1A 228717
PUMP, Drive
- Deutz D2.2
P2 161963 PUMP, System
P3 162330 PUMP, System - with 12 kW Generator
PFC1 166055 CONTROL, Priority Flow (Steer)
PFC2 169407 CONTROL, Priority Flow (Generator 3.5kW)
PFC3 N/A CONTROL, Priority Flow (Generator 12kW)
PR1 168754 VALVE, Pressure Reducing
QD1 122420 DISCONNECT, Quick
RV1 N/A VALVE, Relief (Drive Pump)
RV2 N/A VALVE, Relief (Drive Pump)
RV3 N/A VALVE, Relief (Charge Pump)
RV5 N/A VALVE, Relief (EPU)
RV6 166043 VALVE, Relief (Main Control)
RV7 168975 VALVE, Relief (Boom Rotate)
RV8 166044 VALVE, Relief (Riser Down)
RV9 159809 VALVE, Relief (Platform Level)
RV10 195600 VALVE, Relief (3.5 kW Generator Option)
RV11 209466 VALVE, Relief (12 kW Generator Option)
RV12 195596 VALVE, Relief (3.5 kW Generator Option)
RV13 195035 VALVE, Relief (Load Circuit)
RV15 209468 VALVE, Relief (Load Circuit)
RV16 209466 VALVE, Relief (12 kW Generator Option)
SV1 141414 SHUTTLE VALVE, Brake Manifold (LS)
SV2 166054 SHUTTLE VALVE, Brake Manifold (M1 / M2)
SV3 N/A SHUTTLE VALVE, Swing Drive
SV4 166054 SHUTTLE VALVE, Main Manifold (Swing)
SV5 166054 SHUTTLE VALVE, Main Manifold (Riser)
SV6 166054 SHUTTLE VALVE, Main Manifold (Boom Lift)
SV7 166054 SHUTTLE VALVE, Main Manifold (Platform Level)
SV8 166054 SHUTTLE VALVE, Main Manifold (Platform Level)
V1 141436 VALVE, Control (Brake Release Override)
V2 166053 VALVE, Control (Loop Flush)
V3 159831 HAND PUMP (Brake Release)
V4 N/A VALVE, Control (Bypass Towing)
3.4 Hydraulic Parts List
