229042ABASJ46 AJ+, SJ46 AJ, SJ51 AJ
Electrical Parts List Section 3 – System Component Identification and Schematics
Index
No.
Skyjack
Part No.
Description
4H-13 159819 COIL, 12 Volt (Boom down valve)
4H-14 159819 COIL, 12 Volt (Boom up valve)
4H-23A 159819 COIL, 12 Volt (Right steer valve)
4H-24A 159819 COIL, 12 Volt (Left steer valve)
4H-30 159819 COIL, 12 Volt (Riser down valve)
4H-31 159819 COIL, 12 Volt (Riser up valve)
4H-32 159819 COIL, 12 Volt (Left turret rotate valve)
4H-33 159819 COIL, 12 Volt (Right turret rotate valve)
4H-34 159821 COIL, 12 Volt (Jib down valve)
4H-35 159821 COIL, 12 Volt (Jib up valve)
4H-36 159821 COIL, 12 Volt (Platform left rotate valve)
4H-37 159821 COIL, 12 Volt (Platform right rotate valve)
4H-38 159821 COIL, 12 Volt (Boom retract valve)
4H-39 159821 COIL, 12 Volt (Boom extend valve)
4H-40 159821 COIL, 12 Volt (Platform level down valve)
4H-41 159821 COIL, 12 Volt (Platform level up valve)
A1 138224 JOYSTICK (Fly boom/Turret)
A2 138225 JOYSTICK (Drive/Steer)
A3 148707 JOYSTICK (Riser boom)
AT1 149426 ANGLE TRANSDUCER
B1 144676 BATTERY, 12V (Wet)
BP1 103057 BEEPER, 4-28 VDC Slow pulsing (Platform control console)
BP2 103056 BEEPER, 7.5-16 VDC (Base control console) (ANSI/CSA & AS)
BP3 144387 ALARM, Overload (CE & AS)
CB1 117325 CIRCUIT BREAKER (15 Amp)
CB2 117325 CIRCUIT BREAKER (15 Amp)
CB3 117325 CIRCUIT BREAKER (15 Amp)
CB4 117326 CIRCUIT BREAKER (20 Amp)
CB6 117326 CIRCUIT BREAKER (20 Amp)
CI 152323 INDICATOR, Charge
DXX 102921 DIODE
FU1 138848 FUSE, 50 Amp
FS1 138230 SWITCH, Low fuel
H1 146652 HORN, 12 Volt
LS1 122007 SWITCH, Limit (Direction sensing)
LS2 111356 SWITCH, Limit (Riser down)
LS3 161582 SWITCH, Limit (Boom down)
LS4 160018 SWITCH, Limit (Fly in)
M1 706921 PUMP, Emergency
PL1 148971 LIGHT, Pilot (Engine fault)
PL2 148972 LIGHT, Pilot (Glow plug)
PL3 147229 LED BLOCK, Red (12 volts) (Base control console)
PL4 147229 LED BLOCK, Red (12 volts) (Platform control console)
PL5 138229 MODULE, Upper indicating
PL6 148971 LIGHT, Pilot (Platform control console)
3.5 Electrical Parts List
