Skyjack SJ46 AJ+ Service Manual

62
229042ABA SJ46 AJ+, SJ46 AJ, SJ51 AJ
Section 3 – System Component Identification and Schematics Electrical Parts List
Index
No.
Skyjack
Part No.
Description
QD1 122420 QUICK DISCONNECT (CE & AS)
R1 110999 RESISTOR, 5 ohm 25 W
R2 151643 RESISTOR, 250 ohm 1 W
R3 163021 RESISTOR, 120 ohm 1/2 W
R4 164859 RESISTOR, 2.2k ohm 1/2 W
R5 143952 RESISTOR, 51 ohm 2 W (Deutz D2011 and Kubota)
164858 RESISTOR, 2.1k ohm 1/2 W (Deutz D2.9L)
R6 164857 RESISTOR, 3.9k ohm 1/2 W
R7 144492 RESISTOR, 680 ohm 1 W (Deutz D2.9L)
151643 RESISTOR, 250 ohm 1 W (Deutz D2011 and Kubota)
S1 119725 SWITCH, Main power disconnect
S2 138277 KEYSWITCH, Base/Off/Platform (Base control) (ANSI/CSA, AS Deutz D2011)
164949 KEYSWITCH, Base/Off/Platform (Base control) (ANSI/CSA Deutz D2.9L)
144366 KEYSWITCH, Base/Off/Platform (Base control) (CE)
S3 147053 N.C. CONTACT, Emergency stop (Base control console)
S4 147053 N.C. CONTACT, Emergency stop (Platform control console)
S5 138278 SWITCH, Ignition/emergency pump toggle (Base control console)
S6 138278 SWITCH, Ignition/emergency toggle (Platform control console)
S8 102853 SWITCH, Diagnose toggle (Base control console) (Deutz engine)
S9 124446 SWITCH, Ignition (Platform control console)
S10 115574 SWITCH, Throttle toggle (Platform control console)
S11 138721 ASSEMBLY, Footswitch
S12 138278 SWITCH, Boom up/down toggle (Base control console)
S13 102853 SWITCH, Turret rotate toggle (Base control console)
S14 102853 SWITCH, Telescope in/out toggle (Base control console)
S15 102853 SWITCH, Platform leveling toggle (Base control console)
S16 102853 SWITCH, Platform rotate toggle (Base control console)
S17 102853 SWITCH, Jib up/down toggle (Base control console)
S18 138278 SWITCH, Telescope in/out toggle (Platform control console)
S19 138278 SWITCH, Platform leveling toggle (Platform control console) (ANSI/CSA)
S20 138278 SWITCH, Platform rotate toggle (Platform control console)
S21 138278 SWITCH, Jib up/down toggle (Platform control console)
S23 147054 N.O. CONTACT, Horn (Platform control console)
S25 138278 SWITCH, Riser boom up/down toggle (Base control console)
S26 115574 SWITCH, Fuel select (Platform control console) (GM engine)
S28 148998 SWITCH, Differential (Platform control console)
S48 115747 SWITCH, Drive torque toggle (Platform control console)
SMB1-105 218381 MODULE, Master
SMB1-106 218382 MODULE, Slavew
TT1 103336 HOUR METER
X22 138576 PORT, Diagnose (Deutz engine)
X23 138574 CONNECTOR, Engine (Deutz engine)
3.5 Electrical Parts List
