Telescopic Boom Series
Models SJ61T & SJ66T
194312
December 2007 Page 153
Section 5 - Procedures Service and Maintenance
OCM Operating Values Chart
Input Expected Value Description
AI 1 0.5V to 8.5V Drive Joystick
AI 2 0.5V to 8.5V Turret Rotation Joystick
AI 3 0.5V to 8.5V Boom Elevation Joystick
AI 4 0.5V to 7.5V Flow Enable Rotary Potentiometer
DI 1 0 or 1 Direction Reverse Limit Sw.
DI 2 0 or 1 Footswitch Actuated
DI 3 0 or 1 Telescope Out Toggle Switch
DI 4 0 or 1 Telescope In Toggle Switch
DI 5 0 or 1 Jib Toggle Enabled
DI 6 0 or 1 Platform Rotation Toggle Enabled
DI 11 0 or 1 High Speed Drive Enable Limit Switch
Output
Adjustable
Parameter
Description
PWM 1 25 to 75% Drive Reverse
PWM 2 25 to 75% Drive Forward
PWM 3 21 to 35% Turret Rotate Left
PWM 4 21 to 35% Turret Rotate Right
PWM 5 21 to 35% Main Boom Down
PWM 6 38 to 47% Main Boom Up
PWM 7 0 to 100% Jib and Platform Rotate
PWM 11 40 to 48% Boom Telescope Retract
PWM 12 45 to 70% Boom Telescope Extend
Output Expected Value Description
DOUT 1 0 or 1 Steering Reverse Relay
DOUT 2 0 or 1 Load Sense Valve Enable
DOUT 3 0 or 1 Footswitch Actuated Indicator
DOUT 4 0 or 1 Holding Brake OFF (Energize to release)
DOUT 5 0 or 1 Manual Platform Level Enable
60583AB
