Page 192 December 2007
Telescopic Boom Series
Models SJ61T & SJ66T
194312
Section 5 - ProceduresService and Maintenance
Deutz Diesel Engine
Maintaining the engine components is essential to good
performance and service life of the aerial platform.
5.4-1 Replace Engine Oil and Filter
Periodic replacement of the engine oil and lter is es-
sential to good engine performance.
NOTE
Perform this operation after warming the
engine to normal operating temperature.
CAUTION
Beware of hot engine components.
Contact with hot engine components
may cause severe burns.
CAUTION
When draining hot oil, there is a risk of
scalding. Do not let used oil run into
the soil, rather collect it in a container.
Dispose of this in accordance with en-
vironmental regulations.
1. Ensure aerial platform is on a firm level
surface.
2. Allow engine to warm up.
3. Remove bolts from engine tray.
4. Pull locking pin down and swing the engine
tray away from the turret until it locks in
place.
5. Place suitable container under engine.
6. Remove oil drain plug and allow all engine
oil to drain into container.
7. Install oil drain plug with new seal ring and
tighten rmly.
8. Remove oil lter and catch any escaping oil.
9. Clean inside the lter head.
10. Add clean engine oil to oil lter.
11. Apply a thin layer of engine oil to the new oil
lter gasket.
12. Install lter and tighten it by hand.
13. Clean up any oil that may have spilled during
this procedure.
14. Rell engine with new oil as per specications
(Refer to engine manual).
15. Swing engine tray back to its original
position.
16. Reinstall bolts to engine tray.
17. Start engine from base control console and
allow engine to run for 30 seconds then stop
the engine.
18. Check for oil leakage.
19. Check engine oil level on dipstick and add
oil if needed.
NOTE
Refer to your national/local regulations
on how to dispose of used lter and oil.
