Skyjack SJ61T Service Manual

Page 206 December 2007
Telescopic Boom Series
Models SJ61T & SJ66T
194312
Section 5 - ProceduresService and Maintenance
5.6-3 ECU Pin Reference Chart (Kubota WG2503)
B A
75
45
15
90
60
30
76
46
16
61
61
1
Pin WireColour Description Pin WireColour Description
1 YELLOW18 SPK_COIL1A 46 BLANK AUXANAPUD1
2 YELLOW/BLACK18 SPK_COIL1B 47 PURPLE/LT_BLUE18 TPS1
3 YELLOW/RED18 SPK_COIL2A 48 LT_BLUE/DK_BLUE18 TPS2
4 BLACK16 SPK_GRND 49 DK_GREEN/PURPLE18 AUXDIG1
5 YELLOW/WHITE18 SPK_COIL2B 50 TAN/RED18 AUXDIG2
6 BLANK SPK_COIL3A 51 BLACK/YELLOW18 KNK1+
7 BLANK SPK_COIL3B 52 BLACK18 KNK1‐
8 BLANK EGO_3 53 DK_BLUE/ORANGE18 FPP1
9 ‐‐54 PURPLE/YELLOW18 FPP2IVS
10 ‐‐55 BLANK VRELAY
11 ‐‐56 ‐‐
12 ORANGE/YELLOW18 AUXANAPD1 57 BLANK KNK2+
13 WHITE/LT_GREEN18 AUXANAPD2 58 BLANK KNK2‐
14 DKBLUE‐PINK18 CAN1+ 59 BLANK VBATPROT
15 BLUE/WHITE18 CAN1‐ 60 RED/TAN16 VBAT
16 ‐‐61 BLACK/YELLOW18 EGOH2
17 ‐‐62 BLACK/WHITE18 EGOH1
18 BLANK AUXANAPUD3 63 BLANK UEGOC
19 LT_GREEN/RED18 5VEXT1 64 BROWN/LT_BLUE18 INJ1LS
20 BLACK/LT_GREEN18 5VRTN1 65 BROWN/LT_GREEN18 INJ2LS
21 DK_GREEN/ORANGE18 EGO1 66 BROWN/YELLOW18 INJ3LS
22 DK_GREEN/WHITE18 EGO2 67 BROWN/WHITE18 INJ4LS
23 LT_GREEN18 MAP 68 BLANK INJ5LS
24 BLANK AUXANAPUD3 69 BLACK16 GROUND
25 PURPLE/WHITE18 CRANK+ 70 BLANK INJ6LS
26 WHITE/PURPLE18 CRANK‐ 71 BLANK AUXPWM8
27 GRAY/BROWN18 CAM+ 72 PINK/BLACK18 STARTER
28 PURPLE/ORANGE18 CAM‐ 73 WHITE/LT_BLUE18 RELAY
29 RED/WHITE18 SPEED+ 74 GREEN/YELLOW18 MIL
30 RED/BLACK18 SPEED‐ 75 BLANK EGOH_3
31 LT_GREEN/PURPLE18 5VEXT2 76 BLANK AUXPWM7
32 LT_GREEN/B;ACK18 5VRTN2 77 WHITE/BLACK18 LOCKOFF
33 BLANK PULSE_IN 78 TAN/BLACK18 AUXPWM6
34 GRAY/DK_BLUE18 GOV1 79 RED/TAN16 VBAT
35 LT_BLUE18 OILPRESSURE 80 PINK/WHITE18 DBW+
36 YELLOW/GRAY18 IAT 81 BLACK16 GROUND
37 TAN/WHITE18 ECT 82 TAN/ORANGE18 DBW‐
38 LT_GREEN/WHITE18 AUXANAPU1 83 WHITE/BROWN16 AUXOWM5REC
39 YELLOW/DK_BLUE18 AUXANAPU2 84 BROWN/WHITE16 AUXPWM5
40 DK_BLUE/YELLOW18 AUXANAPU3 85 TAN16 AUXPWM1
41 TAN/DK_GREEN18 AUXDIG3 86 BLANK AUXPWM4
42 GRAY/RED18 AUXDIG4 87 DK_BLUE18 AUXPWM2
43 GRAY18 TACH 88 BLANK AUXPWM4REC
44 PINK/TAN18 VSW 89 PINK/YELLOW16 AUXPWM3REC
45 BLANK AUXANAPUD2 90 BLACK/RED16 AUXPWM3REC
