Skyjack SJ61T Service Manual

Telescopic Boom Series
Models SJ61T & SJ66T
194312
December 2007 Page 193
Section 5 - Procedures Service and Maintenance
5.4-2 Replace Fuel Filter
1. Remove bolts from engine tray.
2. Pull locking pin down and swing the engine
tray away from the turret until it locks in
place.
3. Close fuel shut-off valve.
4. Place suitable container under engine.
5. Remove fuel lter and catch any escaping
fuel.
6. Clean any dirt from lter carrier sealing surface.
7. Apply a thin layer of oil or diesel fuel to
rubber gasket of new fuel lter.
8. Install fuel lter and tighten it by hand then
tighten lter cartridge with nal half-turn.
9. Clean up any fuel that may have spilled
during this procedure.
10. Open fuel shut-off valve.
11. Check for fuel leakage.
12. Swing engine tray back to its original
position.
13. Reinstall bolts to engine tray.
NOTE
Refer to your national/local regulations
on how to dispose of used lter and oil.
5.4-3 Replace Air Filter
Engine specications require that this procedure be
performed more often if dusty conditions exist. Refer
to engine manual.
CAUTION
Perform this procedure with the engine
off.
1. Remove mounting fasteners from air lter
canister and remove end cap.
2. Remove lters from inside of canister.
3. Clean inside of canister and gasket with a
dry cloth.
4. Insert new lters inside of canister.
5. Reinstall end cap.
5.4-4 Check Engine Belt
The aerial platform will not operate properly with a
loose or defective belt. Continuous usage may cause
component damage.
WARNING
Do not inspect while the engine is run-
ning. Remove the key to secure from
operation.
CAUTION
Beware of hot engine components.
Contact with hot engine components
may cause severe burns.
1. Inspect the engine belt for:
• cracking
• glazing
• separation
• breaks
2. For correct tension of engine belt, refer to
engine manual.
5.4-5 Check Oil Cooler
1. Remove cover from the side of engine.
2. Inspect oil cooler for leaks and physical
damage.
3. Clean oil cooler of any kind of debris.
4. Reinstall cover.
