Page 26 December 2007
Telescopic Boom Series
Models SJ61T & SJ66T
194312
Section 2 - Maintenance Tables and DiagramsService and Maintenance
Table 2.1 Standard Hose Numbering System
H1104 0081 2
FITTING
ARRANGEMENT
(See Schedule
Below)
HOSE SIZE
(See Chart
Below)
LENGTH OF HOSE IN
WHOLE INCHES
LENGTH IN
FRACTIONS (1/4"
INCREMENTS) I.E.
1=1/4"
2=1/2"
3=3/4"
Using the number above as an example (H1104 0081 2). This hose requires a 37° JIC, female swivel tting
on one end. A medium length 90° JIC, female swivel tting for the other end. The Hose must meet or exceed
S.A.E. 100R13 hose specication, and be a total of 81-1/2" long. NOTEHose ends and hose must be from
same manufacturer per S.A.E. J1273 Nov. ‘91, Sections 3.10 and 4.2. Hose ends and hose must be of the
same size i.e. #4 size ttings must be used with #4 size hose.
SIZE 03 04 06 08 10 12 16 20 24 32 40 48 56 64
ID 3/16" 1/4" 3/8" 1/2" 5/8" 3/4" 1" 1-1/4" 1-1/2" 2" 2-1/2" 3" 3-1/2" 4"
Hose Size Chart
HOSE PREFIX HOSE END FITTING HOSE END FITTING
S.A.E. HOSE
SPECIFICATION
H01 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R17
H02 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R13
H03 FEMALE, 37° JIC, SWIVEL 45°, FEMALE, 37° JIC, SWIVEL 100R17
H04 FEMALE, 37° JIC, SWIVEL 45°, FEMALE, 37° JIC, SWIVEL 100R13
H05 FEMALE, 37° JIC, SWIVEL LONG 90°, FEMALE, 37° JIC, SWIVEL 100R17
H06 FEMALE, 37° JIC, SWIVEL SHORT 90°, FEMALE, 37° JIC, SWIVEL 100R17
H07 LONG 90°, FEMALE, 37° JIC, SWIVEL LONG 90°, FEMALE, 37° JIC, SWIVEL 100R17
H08 FEMALE, 37° JIC, SWIVEL FEMALE, 37° JIC, SWIVEL 100R4
H09 FEMALE, 37° JIC, SWIVEL 45°, FEMALE, 37° JIC, SWIVEL 100R4
H10 FEMALE, 37° JIC, SWIVEL MALE PIPE THREAD FITTING 100R17
H11 FEMALE, 37° JIC, SWIVEL MEDIUM 90°, FEMALE, 37° JIC, SWIVEL 100R13
H12 SHORT 90°, FEMALE, 37° JIC, SWIVEL SHORT 90°, FEMALE, 37° JIC, SWIVEL 100R17
H13 FEMALE, 37° JIC, SWIVEL REUSABLE MALE PIPE THREAD FITTING 300 PSI
H14 REUSABLE MALE PIPE THREAD FITTING NO FITTING 300 PSI
H15 REUSABLE FEMALE, 37° JIC, SWIVEL REUSABLE FEMALE, 37° JIC, SWIVEL 300 PSI
Fitting Arrangement Schedule (Continued on the following page)
