Skyjack SJ61T Service Manual

Page 28 December 2007
Telescopic Boom Series
Models SJ61T & SJ66T
194312
Section 2 - Maintenance Tables and DiagramsService and Maintenance
Table 2.2 Aerial Platform Torque Specifications
Location Description Torque (ft-lb) Torque (Nm)
Trunnion Mount BOLT, Hex head (3.4"-10 x 4.5", Grade 8) 210 285
Rear Axle Mount BOLT, Hex head (M20 x 2.5 120mm, Grade 10.9) 210 285
Oscillating axle Mount BOLT, Hex head (M20 x 2.5 120mm, Grade 10.9) 280 380
Lockout Cylinder Pin BOLT, Hex head (3/8"-16 x 1", Grade 5) 23 31
Swing Drive Motor BOLT, Hex head (3/4"-10 x 2", Grade 8) 280 380
Rotation Gear (40T / 45T) BOLT, Hex head (5/8"-11 x 4.5", Grade 8) 205 278
Rotation Gear (61T / 66T) BOLT, Hex head (3/4"-10 x 5", zinc, Grade 5) 280 380
Hydraulic Drive Motor BOLT, Hex head (M14 x 2 x 30mm, ZP, Grade 8.8) 80 108
Wheel Nut NUT, Wheel 247-302 335-410
Rotation Gear (40T / 45T) BOLT, Hex head (5/8"-11 x 4.5", Grade 8) 205 278
Rotation Gear (61T / 66T) BOLT, Hex head (3/4"-10 x 4", zinc, Grade 5) 280 380
Deutz Engine Mount BOLT, Hex head (1/2"-13 x 3.75", Grade 5) 55 75
Coupling Assembly (Deutz) BOLT (M10) 29-33 39-45
Muffler NUT 40 55
GM Engine Mount NUT, Hex head (1/2"-13, Grade 5) 50 68
Lift ROD NUT 425 576
Extension (61T/66T) ROD NUT 300 407
Extension (40T/45T)
Master
Slave
Jib
Axle Lockout
BOLT, Hex head (3/4"-10 x 2.5", Grade 5) 210 285
BOLT, Hex head (3/4"-10 x 2.5", Grade 8) 200 271
Master Cylinder Pin
(
40T/45T
)
SCREW, Socket head cap (1/2"-13 x 1", nylon, patch, zinc) 80 108
BOLT, Hex head, patch (3/8"-16 x 7/8", zinc, Grade 8) 35 48
BOLT, Hex head (1"-8 x 10.5", zinc, Grade 8) 480 569
Rotary Manifold BOLT, Hex head (1/2"-13 x 2", Grade 8) 80 108
Rotary Actuator BOLT, Hex head (3/4"-10 x 3", Grade 8) 210 285
BOLT, Hex head patch (ZP, M16 x 1.5 x 4.5", Grade 8.8) 130 177
BOLT, Hex head (1/2"-13 x 2.25", Grade 8) 80 108
Generator Support (40T/45T) BOLT, Hex head (1/2"-13 x 2", Grade 8) 55 75
Oil Cooler Support (40T/45T) BOLT, Hex head (1/2"-13 x 2", Grade 8) 55 75
60580AJ
Special Options (If equipped)
Rotary Mount
Platform
Load Cell Mounting (CE)
Lift Cylinder Bracket
(40T/45T)
Base
Cylinders
Engine (40T/45T)
ROD NUT 475350
Turret
AB
