Diagram 2.3 Axle Oscillation Diagrams
WARNING
Do not raise the platform in work mode if it is not on a rm level surface.
Axle oscillation free (travel mode) - drive speed 4.5 mph max.
Axle oscillation locked (work mode) - drive speed 0.5 mph max.
Axle Oscillation - No Jib Boom
Axle oscillation free (travel mode) - drive speed 4.5 mph max.
Axle oscillation locked (work mode) - drive speed 0.5 mph max.
Axle Oscillation - Jib Boom
