Maintenance
5.19
204-0301 SENSOR FOR SANITARY PRESSURE TRANSMITTER (CONTINUATION)
CODE
Flanges Bolts and Nuts Material
A0
A1
A2
Plated Carbon Steel (Default) 13)
316 SST
Carbon Steel (ASTM A193 B7M) (1) (13)
A5
Hastelloy C276
CODE
Flange Thread for Fixing Accessories (Adapters, Manifolds, Mounting Brackets, etc)
D0
D1
7/16” UNF (Default)
M10 X 1.5
D2
M12 X 1.75
 TYPICAL MODEL NUMBER
NOTES
( 1 ) Meets NACE MR – 01 – 75/ISO 15156 recommendations.
( 2 ) Silicone Oils not recommendations for Oxygen (O
2
) or Chlorine service.
( 3 ) Not applicable for vacuum service.
( 4 ) Drain/Vent not applicable.
( 5 ) O’Ring should be Viton or Kalrez.
( 6 ) Maximum pressure 24 bar.
( 7 ) For remote Seal only 316 SST - CF8M (ASTM A3510 flange is available (thread M12).
( 8 ) HP – High Pressure
( 9 ) Not available for tri-clamp connections.
(10) Compliant with 3A-7403 standard for food and other applications where sanitary connections are required:
- Neobee M2O Fill Fluid
- Finishing wet Face: 0.8 µm Ra (32 µ" AA)
- Wet O-Ring: Viton, Buna-N and Teflon
(11) Item by inquire.
(12) Inert Fluid: safe for oxygen service.
(13) Not applicable for saline atmosphere.
204-0301 A0 D0
