Technical Characteristics
6.7
Notes
( 1 ) Meets NACE MR – 01 – 75/ISO 15156 recommendations.
( 2 ) Not available for absolute models nor vacuum applications.
( 3 ) Not available for range 0 and 1.
( 4 ) Not recommended for vacuum service.
( 5 ) Maximum pressure 24 bar (350 psi).
( 6 ) Options not certified for hazardous locations.
( 7 ) Drain/Vent not applicable.
( 8 ) For remote seal only 316 SST – CF8M (ASTM A351) flange is
available (thread 7/16 UNF).
( 9 ) Silicone Oil is not recommended for oxygen (O2) or Chlorine service.
(10) Only available for differential pressure transmitters.
(11) O’Ring should be Viton or Kalrez.
(12) Not available for range 0.
(13) Only available for pressure transmitters D4 or H4 and 7/16 UNF or M10 x 1.5 flange thread
for fixing accessories.
(14) Only available for flange with PVDF (Kynar) insert.
(15) Inert Fluid: Safe for oxygen service.
(16) Not applicable for saline atmosphere.
(17)
Certificate for use in Hazardous Locations (CEPEL, NEPSI, NEMKO, EXAM, FM, CSA).
(18)
Certificate for use in Hazardous Locations (CEPEL, CSA).
(19)
Certificate for use in Hazardous Locations (CEPEL, NEPSI, NEMKO, EXAM).
LD301
DIFFERENTIAL, FLOW, GAGE, ABSOLUTE AND HING STATIC PRESSURE TRANSMITTER (CONTINUATION)
COD.
Flanges Bolts and Nuts Material
A0
A1
A2
Plated Carbon Steel (Default) (6)
316 SST
Carbon Steel (ASTM A193 B7M) (1) (6)
A5
Hastelloy C276
COD.
Flange thread for fixing accessories (adapters, manifolds, mounting brackets, etc)
D0
D1
7/16” UNF (Default)
M10 X 1.5
D2 M12 X 1.75
COD.
Output Signal
G0
G1
G3
4 – 20 mA (Default)
0 – 20 mA (4 wires) (2)
NAMUR NE extended 4-20 mA (Burnout 3,55 to 22,8 mA)
COD.
Housing Material (8) (9)
H0
H1
H2
Aluminum (Default) (IP/TYPE)
316 SST – CF8M (ASTM – A351) IP/TYPE)
Aluminium for saline atmosphere (IPW/TYPEX) (7)
H3
H4
316 SST for saline atmosphere (IPW/TYPEX) (7)
Copperfree Aluminium (IPW/TYPEX) (7)
COD.
Tag Plate
J0
J1
J2
With tag, when specified (Default)
Blank
According to user’s notes
COD.
PID Configuration
M0
M1
With PID (Default)
Without PID
COD.
LCD1 Indication
Y0
Y1
Y2
LCD1: Percentage (Default)
LCD1: Current – I (mA)
LCD1: Pressure (Engineering Unit)
Y3
YU
LCD1: Temperature (Engineering Unit)
LCD1: According to user notes (4)
COD.
LCD2 Indication
Y0
Y4
Y5
LCD2: Percentage (Default)
LCD2: Current – I (mA)
LCD2: Pressure (Engineering Unit)
Y6
YU
LCD2: Temperature (Engineering Unit)
LCD2: According to user notes (4)
COD.
Identification Plate
I1
I2
I3
I4
I5
I6
FM: XP, IS, NI, DI
NEMKO: Ex-d, Ex-ia
CSA: XP, IS, NI, DI
EXAM (DMT): Ex-ia
CEPEL: Ex-d, Ex-ia
Without Certification
I7
I8
IF
IE
IH
EXAM (DMT): Group I, M1 Ex-ia
0 a 20 mA (2)
CEPEL: Ex-d
NEPSI: Ex-ia (5)
CEPEL + IP68
COD.
Painting
P0
P3
P4
P5
Gray Munsell N 6.5 Polyester
Black Polyester
White Epoxy
Yellow Polyester
P8
P9
PC
Without Painting
Blue Safety Epoxy – Electrostatic Painting
Blue Safety Polyesters – Electrostatic Painting
TYPICAL MODEL NUMBER
Optional Items
*
Leave blank for no optional items
Burn-out
BD – Down Scale (Accordance to NAMUR NE43 specification).
BU – Up Scale (Accordance to NAMUR NE43 specification).
Special Applications C1 – Degrease Cleaning (Oxygen or Chlorine Service) (5).
High Performance L1 – 0.04% accuracy (3).
Square Root Extraction M3 – With Square Root extraction.
Special Features ZZ – User’s specification.
LD301 - D21I - BU10 -
012
A0 D0 G0 H0 J0 M0 Y0 Y4 I6 P0
