SMART Board GX Series - Display Input Connectors and Cables

Chapter 5
Connecting computers and other devices
smarttech.com/kb/171745 58
l As shown below, HDMI 1, HDMI 2, VGA, and Display Port share the Touch USB Type-B receptacle on
the side connector panel, and HDMI uses the Touch USB Type-B receptacle on the front connector
panel (see Sharing USB Type-B receptacles on page66).
l The USB Type-C connector provides 15 W of power for chargeing connected devices.
The following are the locations of the connectors and the connector and cable information for the display’s
input sources.
l USB Type-C
Connector Standard Connection type Cable
USB Type-C USB 3.2 Gen 1
(SuperSpeed, 5 Gbps)
Video/audio/touch SuperSpeed USB Type-C
