SMC Networks JXC91 User Manual

-39-
No.SFOD-OMT0006-F
●Word1: Controlling of the controller/numerical data flag
Word
Bit
Signal name
Description
1
0
Flags for controller
(Unused)
Set it always OFF(0)
1
Speed restriction
Speed is restricted for all operations. Value for speed limit
varies depending on actuator type.
2
(Unused)
Set it always OFF(0)
3
(Unused)
Set it always OFF(0)
4
Numerical data input flag
Movement mode
When the operation is commanded numerically, values can
be changed while the set values are ON. (7)
5
Speed
6
Position
7
Acceleration
8
Deceleration
9
Pushing force
10
Trigger LV
11
Pushing speed
12
Moving force
13
AREA 1
14
AREA 2
15
In-Position
●Word2: Movement mode/Start flag
Word
Bit
Signal name
Description
2
0
Start flag
Data transmission flag during numerically instructed
operation. Turn OFF during waiting for transmitting. Turn ON
when transmitting numerical data to the controller. (7, 8, 9)
1-7
(Unused)
Set it always OFF(0)
8-9
Movement mode
1: ABS (Absolute) 2: INC (Relative) (7, 10)
10-15
(Unused)
Set it always OFF(0)
●Word3: Speed
Word
Bit
Signal name
Description
Input range
Min. unit
3
0-15
Speed
1 ~ Basic parameters
"Maximum speed" (7, 11)
1 mm/s
●Word4, 5: Target position
Word
Bit
Signal name
Description
Input range
Min. unit
4
0-15
Target Position (Lower digits)
Basic parameter
"Stroke(-)" - "Stroke (+)" (5, 7, 11)
0.01 mm
5
0-15
Target Position (Upper digits)
●Word6: Acceleration
Word
Bit
Signal name
Description
Input range
Min. unit
6
0-15
Acceleration
1 ~ Basic parameters
"Maximum acceleration/deceleration
speed" (7, 11)
1 mm/s
2
5 Please refer to 21. Handling of sent/received data (P.83) for handling of the data.
7 Change the numerical data input flag and the numerical data only when the start flag is OFF.
If the numerical data input flag or the numerical data are changed when the start flag is ON, it may
lead to unexpected operation.
8 Turn ON the start flag from OFF only when stopped. If the numerical data input flag or the
numerical data is changed while operating, it may lead to unexpected operation.
9 To avoid unintentionally changing the numerical data, it is recommended to turn OFF the start flag
after starting an operation.
10 Do not input numbers other than [1(ABS)] and [2(INC)].
11 The actuator model determines the limit for the input values. Please refer to the manual of the
actuator for more details.
