●Word7: Deceleration
Word
Bit
Signal name
Description
Input range
Min. unit
7
0-15
Deceleration
1 ~ Basic parameters
"Maximum deceleration speed" (7, 11)
1 mm/s
2
●Word8: Pushing force
Word
Bit
Signal name
Description
Input range
Min. unit
8
0-15
Pushing force
(Thrust setting value)
(7, 11)
1%
●Word9: Trigger LV
Word
Bit
Signal name
Description
Input range
Min. unit
9
0-15.
Trigger LV
(7, 11)
1%
●Word10: Pushing speed
Word
Bit
Signal name
Description
Input range
Min. unit
10
0-15
Pushing speed
(7, 11)
1 mm/s
●Word 11: Moving force
Word
Bit
Signal name
Description
Input range
Min. unit
11
0-15
Moving force
(7, 11)
1%
●Word12, 13: AREA 1
Word
Bit
Signal name
Description
Input range
Min. unit
12
0-15
AREA 1 (Lower digits)
Basic parameter
"Stroke (-)" - "Stroke (+)" (5, 7, 11)
0.01 mm
13
0-15
AREA 1 (Upper digits)
●Word14, 15: AREA 2
Word
Bit
Signal name
Description
Input range
Min. unit
14
0-15
AREA 2 (Lower digits)
Basic parameter
"Stroke (-)" - "Stroke (+)" (5, 7, 11)
0.01 mm
15
0-15
AREA 2 (Upper digits)
●Word16, 17: In-Position
Word
Bit
Signal name
Description
Input range
Min. unit
16
0-15
In-Position(Lower digits)
(5, 7, 11)
0.01 mm
17
0-15
In-Position(Upper digits)
5 Please refer to 21. Handling of sent/received data (P.83) for handling of the data.
7 Change the numerical data input flag and the numerical data only when the start flag is OFF. If the
numerical data input flag or the numerical data are changed when the start flag is ON, it may lead to
unexpected operation.
11 The actuator model determines the limit for the input values. Please refer to the manual of the
actuator for more details.
