SMC Networks SMCGS10C-Smart User Manual

C HAPTER 3 | Using the Web Interface
Navigating the Web Browser Interface
– 37 –
Port Security
Switch Shows information about MAC address learning for each
port, including the software module requesting port security
services, the service state, the current number of learned
addresses, and the maximum number of secure addresses
allowed
207
Port Shows the entries authorized by port security services,
including MAC address, VLAN ID, the service state, time
added to table, age, and hold state
209
NAS Shows global and port settings for IEEE 802.1X
Switch Shows port status for authentication services, including
802.1X security state, last source address used for
authentication, and last ID
210
Port Displays authentication statistics for the selected port –
either for 802.1X protocol or for the remote authentication
server depending on the authentication method
211
ACL Status Shows the status for different security modules which use
ACL filtering, including ingress port, frame type, and
forwarding action
215
DHCP Dynamic Host Configuration Protocol
Snooping
Statistics
Shows statistics for various types of DHCP protocol packets 217
Relay
Statistics
Displays server and client statistics for packets affected by
the relay information policy
218
ARP Inspection Displays entries in the ARP inspection table, sorted first by
port, then VLAN ID, MAC address, and finally IP address
219
IP Source Guard Displays entries in the IP Source Guard table, sorted first by
port, then VLAN ID, MAC address, and finally IP address
220
AAA Authentication, Authorization and Accounting 221
RADIUS
Overview
Displays status of configured RADIUS authentication and
accounting servers
221
RADIUS Details Displays the traffic and status associated with each
configured RADIUS server
222
LACP Link Aggregation Control Protocol 225
System Status Displays administration key and associated local ports for
each partner
225
Port Status Displays administration key, LAG ID, partner ID, and partner
ports for each local port
226
Port Statistics Displays statistics for LACP protocol messages 227
Spanning Tree 228
Bridge Status Displays global bridge and port settings for STA 228
Port Status Displays STA role, state, and uptime for each port 230
Port Statistics Displays statistics for RSTP, STP and TCN protocol packets 231
MVR Multicast VLAN Registration 232
Statistics Shows statistics for IGMP protocol messages used by MVR 232
Group Information Shows information about the interfaces associated with
multicast groups assigned to the MVR VLAN
233
Table 4: Main Menu (Continued)
Menu Description Page
