8
Introduction Power Sources
NOTE:
i The Navigation Prompts Tool Setup utility, available in Europe only, can be used to configure the
N/X on-screen control reference to display either N or X. Refer to “Navigation Prompts” on
page 42 for details.
2.4.3 Thumb Pad
The Thumb Pad moves the highlight on-screen and is typically used in combination with the Y/a
(Yes) and N/X (No) buttons.
2.4.4 Brightness/Contrast (S Button)
The Brightness/Contrast button operates as a user-adjustable, multi-function button. The function
preference is set up from the Utilities > Tool Setup > Brightness/Contrast Button dialog. Refer to
“Brightness/Contrast Button” on page 41 for details.
2.4.5 Power Button
The Power button turns the MODIS™ unit on and off.
2.5 Power Sources
Your MODIS™ unit can receive power from any of the following sources:
• AC/DC power supply
• Vehicle auxiliary power cables (12 volt)
• Scanner Plug-in cables
• Battery pack (rechargeable)
2.5.1 AC/DC Power Supply
The MODIS™ unit can be powered from a wall socket using the AC/DC power supply and power
cord (Figure 2-5).
