Dec. address. Hex. address. No. of words Designation Unit
Network configuration
22096 5650 1 Type of network
0: 4NBL (230/400V)
1 : 1BL (230/400V)
2 : 41NBL (230/400V)
3 : 42NBL (230/400V)
4 : 3NBL (230/400V)
5 : 4NBL (127/230V)
6 : 3NBL (127/230V)
7 : 2NBL (127/230V)
8 : 2BL (127/230V)
9 : 42NBL (127/230V)
22097 5651 1 Neutral (0) AUTO 1: neutral on the left 2: Neutral
on the right
22098 5652 1 Direction of phase rotation
0 : Undened 1 : ABC 2: ACB
22099 5653 1 Rated voltage
180 <= Unom <= 480
22100 5654 1 Rated frequency
0 : 50Hz 1 : 60 Hz
22101 5655 1 Application type:
0 : Network - Network (M-M) 1 : Network - genset (M-G)
22103 5657 1 Genset starting relay
0 : NO 1 : NC
22104 5658 1 PRIO NET
0 : none 1 : source
I
2 : Source
II
22105 5659 1 PRIO TON
0 : NO 1 : YES
22106 565A 1 PRIO EON
0 : NO 1 : YES
22107 565B 1 RETRANS
0 : NO 1 : YES
22108 565C 1 RETURN O
0 : NO 1 : YES
22110 565E 1 2ND TRIP
0 : NO 1 : YES
22111 565F 1 MOD AUT
0 : NO 1 : YES
22112 5660 1 BACKLIGHT
0 : OFF 1 : ON 2 : INT
Inputs / outputs configuration
22352 5750 1 Function IN 1
0 : /
22353 5751 1 Function IN 2
0 : /
22354 5752 1 Function IN 3
0 : /
22355 5753 1 IN 1 status 0 : NO 1 : NC
22356 5754 1 IN 2 status 0 : NO 1 : NC
22357 5755 1 IN 3 status
0: NO 1 : NC
22358 5756 1 Function OUT 1
0 : /
22359 5757 1 Function OUT 2
0 : /
22360 5758 1 Function OUT 3
0: /
