13.9.5. Function 6
Dec. address. Hex. address. No. of words Designation Unit
Control
21584 5450 1 Command conguration
0x01: Congure RTE (Back transfer)
0x02: Cancel TOF (Off Load Test)
0x03: Congure TOF (Off Load Test)
0x04: Congure TON (On Load Test)
0x05: Congure EOF (External Off Load)
0x06: Congure EON (External On Load)
0x07: Cancel EOF (External Off Load)
0x08: Cancel EON (External On Load)
0x10: Cancel alarms and faults
0x11: Congure FT1
0x12: Congure FT2
0x13: Congure AL1
0x14: Congure AL2
21585 5451 1 Operating mode conguration
3: Auto
4 : Inhibit
5 : Control
Other: Unchanged
21586 5452 1 Priority conguration
0 : Network
1 : Source
I
2 : Source
II
Other: Unchanged
21587 5453 1 Position conguration
Only available in test mode (address 5451 = 5)
0: None
1 : Position 0
2 : Position I
3 : Position II
