socomec ATyS p M User Manual

35
EN
ATySpM - 542935E - SOCOMEC
13.4.4. Events
13.4.4.1. Encoding principle
Example
12
Type of
message:
M: Event
F: Fault
Source in
question
0: common
1: source I
2: Source II
Message
identification
n°
see opposite
table
Description
Message identication
N° Status message Fault message
0 Manual switching Duty cycle
1 Under-voltage Fault
2 Over-voltage Alarm
3 Under-frequency Neutral wiring / Phase rotation
mismatch
4 Over-frequency Capacitor back to 0
5 Phase unbalance Insufcient switchover power
6 Phase rotation Position not reached
13.4.5. Events list
Message Definition Message Definition
12
Manual switching
12
Over-frequency on source

I
12
Under-voltage on source

I
12
Over-frequency on source
II
12
Under-voltage on source
II
12
Phase unbalance on source

I
12
Over-voltage on source

I
12
Phase unbalance on source
II
12
Over-voltage on source
II
12
Incorrect direction of rotation
on source

I
12
Under-frequency on source

I
12
Incorrect direction of rotation
on source
II
12
Under-frequency on source
II
