socomec ATyS p M User Manual

40
EN
ATySpM - 542935E - SOCOMEC
13.5.4. SETUP Menu
12
Definition Adjustment range Default values M-G* M-M*
21
NETWORK Type of network 4NBL/41NBL/-
42NBL/ 1BL/3NBL
(230/400V version)
4NBL/3NBL/2NBL/
-2BL/42NBL
(127/230V version)
4NBL
• •
12
NEUTRAL Position of neutral
- AUTO : neutral position is set
automatically upon every power-up.
This conguration cannot be used
with a 3NBL 400 Vac network + auto
transformer
- LEFT : neutral must be connected
on the left, i.e. to terminal 1 of each
switch
- RIGHT : neutral must be connected
on the right, i.e. to terminal 7 of each
switch
Auto
LEFT
RIGHT
Auto
• •
CHECK
ROT
The phase rotation verication can
be disabled. When disabled the ATyS
will transfer normaly even if the two
sources have different direction of
rotation. This should be used only
when the load is not affected by phase
rotation changes.
YES
NO
YES
• •
12
ROT PH. The phase rotation can be selected as
clockwise (ACB) or anti-clockwise (ABC).
It is also possible to just check for
consistency of direction of rotation
between 2 sources (----). To do so the 2
sources must be simultaneously present,
for example during the initial wiring. (see
next page)
ABC
ACB
---
- - -
• •
12
NOM. VOLT Nominal phase-phase voltage. Except
for 1BL and 41NBL networks, where
it is nominal phase-neutral voltage.
from 180 to 480 Vac
(230/400V version)
400Vac
(version 230/400V)
• •
from 180 to 280 Vac
(127/230V version)
230Vac
(version 127/230V)
12
NOM. FREQ Rated frequency 50 or 60 Hz 50 Hz
• •
12
APP Application type:
- M-G : between a network and
genset
- M-M : between two networks
M-G
M-M
M-G
• •
12
GE START "Generator start signal” output status
at rest
- NO : Normal Open
- NC : Normal Close
NO
NC
NO
•
12
PRIO TON
In case of an On Load Test, if source
II
is no longer available you can
- NO :
exit the test and switch to source
I
- YES : stay in position II. The MSR input
(see I-O Menu) has priority over this
parameter
NO
YES
NO
•
12
PRIO EON
(1)
In case of External On Load, if source
II
is no longer available you can
- NO :
exit the test and switch to
source
I
- YES : stay in position II. The MSR input
(see I-O Menu) has priority over this
parameter
NO
YES
NO
•
* M-G : network - genset application - M-M: network - network application
• = parameter present on M-G and/or M-M applications
(1) This parameter is only accessible if a programmable input is congured with the EON variable (see I/O menu).
