6. TECHNICAL DATA
Ratings 40A 63 A 80 A 100 A 125 A 160 A
Frequencies
50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz
Thermal current Ith at 40°C (A) 40 63 80 100 125 160
Thermal current Ith at 50°C (A) 40 63 80 100 110* 125
Thermal current Ith at 60°C (A) 40 50 63 80 100* 125
Thermal current Ith at 70°C (A) 40 40 50 63 80* 100
Rated assigned insulation voltage Ui (V) (Power
circuit)
800 800 800 800 800 800
Rated impulse withstand voltage U
imp
(kV) (power circuit) 6 6 6 6 6 6
Rated insulation voltage U
i
(V) (control circuit) 300 300 300 300 300 300
Rated impulse withstand voltage U
imp
(kV) (control circuit) 2.5 2.5 2.5 2.5 2.5 2.5
Rated operational
currents (A)
IEC 60947-3 at 415 VAC
at 40°C
AC 21A / 21 B 40/40 63/63 80/80 100/100 125/125 160/160
AC 22A / 22 B 40/40 63/63 80/80 100/100 125/125 125/160
AC 23A / 23 B 40/40 63/63 80/80 100/100 125/125 125/160
Rated operational
currents (A) IEC 60947-6-
1 415Vac at 40°C
AC 33B / AC32B
**AC 33iB
40/40 63/63 80/80 100/100 125/125 125**/160
Fuse protected short-
circuit withstand if using
gG DIN fuses
Fuse protected short-
circuit withstand (kA eff)
50 50 50 50 50 40
Associated fuses (gG DIN) 40 63 80 100 125 160
Short-circuit capacity Rated short-term
withstand current: Icw 1s
(kA eff)
4 4 4 4 4 4
Rated short-term
withstand current: Icw
30ms (kA eff)
10 10 10 10 10 10
Switching time at In
excluding loss of supply
sensing time and
excluding any delay
timers applicable.
I-II or II-I (ms) 180 180 180 180 180 180
Duration of “electrical
blackout” at Un (ms)
90 90 90 90 90 90
I-O / O-I / II-O / O-II (ms) 45 45 45 45 45 45
Consumption Inrush current(A) 20 20 20 20 20 20
Consumption in stabilised
state (VA)
6 6 6 6 6 6
Mechanical
characteristics
Number of changeovers 10000 10000 10000 10000 10000 10000
Connection cross-section
(
not compatible with
aluminium cables)
Minimum size (Cu mm²),
exible and rigid
10 10 10 10 10 10
Maximum size (Cu mm²),
exible and rigid
70 70 70 70 70 70
Equipment class (According to IEC 60947-6-1) PC PC PC PC PC PC
EMC environment A A A A A A
* Possibility of reaching 125A with bigger connection cross-sections and use of the 160A bridging bar.
** AC 33iB 160A according to GB 14048.11.
This is a class A product. In a domestic environment, this product may cause radio interference in
which case the user may be required to take adequate measures.
