socomec ATyS - Copper Bar Connection Kits (2000 A to 3200 A: Frame B8)

27
EN
ATyS / ATySr - 541630C - SOCOMEC
6.3.5. Copper bar connection kits (2000A to 3200A : Frame B8)
Dual dimensions in/mm
0.98
25
0.98
25
1.18
30
1.18
30
3.54
90
0.59
15
0.49 12,5
Ø 0.49
Ø 12,5
17.18
436,5
14.96
380
13.6 / 347 (3P)
18.38/467(4P)
18.81 / 478 (3P)
23.54/598(4P)
4.72
120
9.84
250
10.15
258
4.72
120
4.72
120
2.10
53,5
2.02
51,5
6.41
163
8.89
226
1.18 (4x)
30(4x)
Conditions of use of these products
may lead to a derating.
!
SOCOMEC“Applicationguide”
www.socomec.com
3 P 4 P
3 P
4 P
3 P 4 P
provided
fourni
I th = 2000 A1
I th = 2500 A
2
I th = 3200 A
3
9.92
252
2.91
74
1.45
37
2.91
74
2.36
60
1.45
37
5.07
129
6.10
155
VERSION 04
VERSION 01
5.19
132
8.30
211
0.86
22
1.18 (4x)
30(4x)
1.18 (4x)
30(4x)
VERSION 02 - 03 - 05 - 06 - 09 - 12
VERSION 07 - 08 - 10 - 11
708 lb-in
80 Nm
VERSION
Rondelle contact
MOY. M M12
NFE 25 511
H M12
01 HM12-356.8-6x 12x 6x
02 HM12-556.8-3x 6x 3x
03 HM12-556.8-5x 10x 5x
04
HM12-356.8-3x 3x -
HM12-456.8-3x 3x -
05 HM12-656.8-3x 6x 3x
06 HM12-656.8-5x 10x 5x
07 HM12-556.8-3x 6x 3x
08 HM12-556.8-5x 10x 5x
09 HM12-556.8-10x 20x 10x
10 HM12-656.8-3x 6x 3x
11 HM12-656.8-5x 10x 5x
12 HM12-656.8-10x 20x 10x
A
B
Connection reference numbers and contents:
x 1
included with 3200A
product as standard
2619 1200
708 lb-in
80 Nm
x 6
2699 1200
2699 1201
+
708 lb-in
80 Nm
x 1
x 6
2629 1200
+
708 lb-in
80 Nm
x 2
x 6
2639 1200
+
708 lb-in
80 Nm
x 1
x 6
4109 0250
+
708 lb-in
80 Nm
x 1
x 6
4109 0320
DataforBolts,NulsandWashersforBusbarConnections.
TO BE SUPPLIED BY OTHERS
!
Note: Reference numbers and quantity given above and below are for one connection and per pole.
Forafullsetmultiplythequantityindicatedbythenumberofpoles(3or4pole)andthenmultiplyby2(N°ofswitches)
