8.2. Electrical operation
8.2.1. Power supply
TheATySristobepoweredbetweenterminals301and302withasupply
within the limits of :
• 208–277Vac±20%(166–332Vac)
• 50/60Hz±10%
Current Input:
• 10mA(Standbymode)
• 15Amax(Switchingmode)
Surge Protection :
• Vin_sg: 4.8KV – 1.2/50µs
Terminal connector:
• Minimum 1.5mm²
• Maximum2.5mm²
8.2.2. Fixed inputs
8.2.2.1. Description
The ATySrincludesfor5offxedinputsthrougha6pinconnectorinstalled
on the motorisation module. No additional power supply should be used on
these contacts as the inputs MUST be used with the common supply taken
from terminal 317.
The ATySrPowerSupply(301-302)mustbeavailabletoactivateinputs
312 to 317.
Pulsedurationforactivationofcontactinputs:≥60ms.
• Pin312:Remote Control Mode Enable when closed with 317.
Thiscontactmustbeclosedwith317soastoactivateallcontrolinputsexceptfor313thattakespriorityandisactive
immaterial of the state of input 312. Enabling remote control through 312 activates the remote control inputs whilst
inhibiting the ATS module automation.
• Pin313: Position 0 order if closed with 317 when in AUTO. (Force the switch to the OFF Position)
This is a “Priority Order Input” meaning that when closed with 317 it takes priority over all other electrical commands.
The ATySrwillremainin0positionaslongasthecontact313–317remainsclosed.Oncethecontactisopenthe
ATySrisreadytoreceiveneworders.Thiscontactorderisindependentofotherinputsandisalsoenabledwithout312
connected to 317. Impulse duration to activate and start switching to position O is a minimum of 60ms. The product state
will be unavailable.
• Pin314: Position II order if closed with 317.
This contact is active with the ATySrinAUTmodewithcontact312–317closedand313–317open.Impulseduration
to activate and switch to position II is a minimum of 60ms.
• Pin315: Position I order if closed with 317
This contact is active with the ATySrinAUTmodewithcontact312–317closedand313–317open.Impulseduration
to activate and switch to position I is a minimum of 60ms.
• Pin316: Position 0 order if closed with 317
This contact is active with the ATySrinAUTmodewithcontact312–317closedand313–317open.Impulseduration
to activate and switch to position O is a minimum of 60ms. For contactor logic maintain contacts on between terminal 316
and 317.
• Pin317: Common
Common supply for inputs 312 to 316
