8.2.3. Fixed outputs - Dry contacts
8.2.3.1. Description
As standard, the ATySrisequippedwithfourxedoutputslocatedonthe
motorisation module.
(Drycontactstobepoweredbytheuser).
8.2.3.2. Position auxiliary contact
The ATySrisequippedwithintegratedposition(I–O–II)auxiliarycontactoutputsthrough3offmicroswitches.
Pins 13, 04, 14, 24
(NormallyOpencontactswithpin13ascommon)
8.2.3.3. ATySr Product available output (motorisation)
Pin 63A – 64A
(NormallyOpencontactthatisheldclosedwhenthemotorisationisavailable).
Thiscontactgivesconstantfeedbackabouttheproduct’savailabilityandit’scapacitytotransferfromthemainsupplytothe
alternative.ThefeedbackgivenisrelativetothemotorisationmoduleexcludingtheATScontrollerthatmaybemonitored
separately.
The ATySrperformsaselfdiagnosticstestonthemotorisationmoduleatstartup,whenputfromManual->Autoandthen
every 5 minutes. This test ensures that the ATySrisoperationalintermsofcontrolinputs.Shouldoneofthetestsfail,a
secondtestisperformedtoreconrmtheerrorstate.ShouldtheATySrmotorisationmodulebecomeunavailable,contact
63A–64Aareopened,thepower/readyLED’sareswitchedoff,andthefaultLEDisactivated.ThefaultLEDwillremain
activeforaslongassufcientpowerisavailableandthefaultconditionisnotreset.Thefaultisresetwhentheproductis
switched from AUT -> Manual -> Auto mode.
ATySr(Motorisation)ProductAvailable/UnavailableWatchdogrelaywillopenforanyofthefollowingreasonsbelow:For
addedsecurity,“ProductAvailability”isinformativeanddoesnotnecessarilyinhibitmotoroperation.
ProductUnavailable+WarningLEDCondition: Inhibition
Product in manual mode Yes
Motornotdetected(Autotest) No
Control voltage out of range Yes
Operatingfactorfaultactive(N°ofoperations/min) Yes
Powerfail active Yes
Customer input autotest failed No
Invalid product customisation No
Abnormal switching when not in manual mode Yes
Requested position not reached Yes
Locked mode active when not in manual mode Yes
ExternalFault->Userinput No
Unexpectedcurrentowingthroughthemotorwhenidle Yes
Sampling rate for the above is every 10 ms
Exception: motor detection sampling rate is every 5 min
