SolarMax MT Series - Standards and Guidelines; Interfaces; Weight and Dimensions; Warranty Information

52
6MT2 8MT2 10MT2
Standards &
guidelines
EMC EN 61000-3-2 / EN 61000-3-3 / EN 61000-3-11 / EN 61000-
3-12 / EN 61000-6-2 / EN 61000-6-3
Grid connection
2)
VDE-AR-N 4105 / VDE 0126-1-1 A1:2012 / BDEW MS-
Richtlinie / CEI 0-21 / CEI 0-16 / RD 661 / RD 1699 / G59/3 /
G83/2 / PPC Guide / C10/11 / EN 50438 / AS 4777
Device safety
IEC / EN 62109-1/-2
Interfaces Data communication RS485 / Ethernet
Status signalling contact M12 connector with relay as N/C contact / N/O contact
Connection of external grid
monitoring
M12 connector
Weight &
dimensions
Weight 39 kg 39 kg 39 kg
Dimensions in mm
(W x H x D)
550 x 750 x 200
Warranty Standard 5 years / extension to 10, 15, 20, or 25 years possible
1) for AC rated power output
2) max. 700 V with external power limitation
3) contact us if the installation location is at a higher level
4) certicates are not available for all models. Details can be found at www.solarmax.com
13MT2 15MT2 13MT3 15MT3
Input
values
MPP voltage range
1)
370… 750 V
2)
430… 750 V
2)
280… 750 V
2)
320… 750 V
2)
Minimum DC voltage 250 V 250 V 250 V 250 V
Maximum DC voltage 900 V 900 V 900 V 900 V
Maximum DC current 2 x 18 A 2 x 18 A 3 x 16 A 3 x 16 A
Maximum DC short-circuit
current
2 x 18 A 2 x 18 A 3 x 16 A 3 x 16 A
Number of MPP trackers 2 2 3 3
Max. PV generator output
per MPP tracker
9 000 W 9 000 W 9 000 W 9 000 W
String connections 2 x 2 2 x 2 3 x 2 3 x 2
Connection type MC 4 MC 4 MC 4 MC4
Output values Rated output power at
cosφ = 1
13 000 W 15 000 W 13 000 W 15 000 W
Maximum apparent output
power
13 000 VA 15 000 VA 13 000 VA 15 000 VA
Nominal mains voltage 3 x 400 V 3 x 400 V 3 x 400 V 3 x 400V
Maximum AC current 3 x 20 A 3 x 22 A 3 x 20 A 3 x 22 A
Maximum AC short-circuit
current
42 A
peak
42 A
peak
42 A
peak
42 A
peak
Mains nominal frequency
/ range
50 Hz / 45 Hz…55 Hz
Power factor cosφ
adjustable from 0.8 overexcited to 0.8 underexcited
Distortion factor at rated
output power
< 3 %
Connection type Connector (locking)
Grid connection three-phase (3 /N / PE)
Power input at night 0 W
Efciency Max. efciency 98.0 %
European efciency 97. 5 %
