99
Operation on LCD
Region Australia A Australia B Australia C New Zealand
Standarad
Code Name
AS4777_2022
_A
AS4777_2022
_B
AS4777_2022
_C
New Zealand
Setting
Range
Startup-T 60 s 60 s 60 s 60 s
15-1000
s
Restore-T 60 s 60 s 60 s 60 s 15-600 s
Recover-
VH
253 V 253 V 253 V 253 V
Recover-VL 205 V 205 V 205 V 198 V
Recover-FH 50.15 Hz 50.15 Hz 50.15 Hz 50.15 Hz
Recover-FL 47.5 Hz 47.5 Hz 47.5 Hz 47.5 Hz
Start-VH 253 V 253 V 253 V 253 V
Start-VL 205 V 205 V 205 V 198 V
Start-FH 50.15 Hz 50.15 Hz 50.15 Hz 50.15 Hz
Start-FL 47.5 Hz 47.5 Hz 47.5 Hz 47.5 Hz
Setting Charger
The inverter is compatible with lithium-ion battery. You can set the charge & discharge
parameters of battery.
• Max Charge: Maximum charging current of battery
• Max Discharge: Maximum discharging current of battery
• Charger upper limit: Default: 60%, range: 10%-100%
»
The maximum battery SOC when charging.
======Charger=====
>Max Charge
Current:
60.0A
======Charger=====
>Max DisCharge
Current:
60.0A
======Charger=====
>Charger upper limit
100%
Setting Export Control
This function allows the inverter to control the amount of electricity output to the grid. The
user value set must be less than the maximum value. If the user does not want to supply
power to the grid, set User Value to "0".
NOTICE!
• Under Safety Code AS4777, Export Control is in the path of Advance Setting
>
AS4777
Setting. You can set the Soft Limit and Hard Limit of Export Control to control the
power output to grid. Please refer to section AS4777 Setting for details.
