SolaX Power X3-ULTRA Series User Manual

100
Operation on LCD
====Export Control====
>Soft Limit value
30000W
Meter/CT Setting
CT or electricity meter is needed to connect with the inverter. Meter is set by default.
NOTICE!
• If the user has other power generation equipment (such as inverter) at home and
wants to monitor both, the inverter provides Meter 2 communication function to
monitor the power generation equipment.
a. Select and enter the Meter/CT Setting according the setting path.
b. Set the the address and direction of Meter/CT:
»
Case 1: Only CT is connected for the series inverter. No power generation
equipment in the whole system. Please activate the CT selection and choose
the supported CT type. You can check the connection status in Meter/CT
Check.
====CT/MeterSetting====
>Select
CT
====CT/MeterSetting====
>Select
Enable
====CT/MeterSetting====
>CT Type
100A
»
Case 2: Only Meter 1 is connected for the series inverter. No power
generation equipment in the whole system. Please activate the meter
1 selection and set the meter address and direction. You can check the
connection status in Meter/CT Check.
NOTICE!
• CT and meter 1 can not be used simutaneously.
====CT/MeterSetting====
>Select
Meter
====CT/MeterSetting====
>Select
Enable
====CT/MeterSetting====
>Meter 1 Addr
1
====CT/MeterSetting====
>Meter 1 Direction
Positive
»
Case 3: CT and Meter 2 are connected. (CT for SolaX Hybrid inverter,
Meter 2 for another power generation equipment or CT for another power
generation equipment, Meter 2 for SolaX Hybrid inverter) For CT setting,
please refer to Case 1. For meter 2 setting, please set the address and
direction of Meter 2 based on actual connection and Enable the External
INV. You can check the connection status in Meter/CT Check.
