SolaX Power X3-ULTRA Series User Manual

101
Operation on LCD
====CT/MeterSetting====
>Meter 2 Addr
1
====CT/MeterSetting====
>Meter 2 Direction
Positive
====CT/MeterSetting====
>External INV
Enable
»
Case 4: Meter 1 and Meter 2 are connected. (Meter 1 for SolaX Hybrid
inverter, Meter 2 for another power generation equipment or Meter 1 for
another power generation equipment, Meter 2 for SolaX Hybrid inverter).
Please refer to Case 2 for Meter 1 setting and Case 3 for Meter 2 setting. You
can check the connection status in Meter/CT Check.
Setting Self Test (only for CEI 0-21)
The self test function allows users to test the following items: Full Test, Ovp(59.S2) test.
Uvp (s1) test, Uvp (27. s2) test, Ofp (81> .S1) test, Ufp (81 <.S1) test, Ufp (81> .S2) test, Ufp (81
<.S2) test, Ovp10 (59. s1) test.
In the Self Test interface, the user can select All Test or a single test item for testing. All
tests take about 6 minutes. And it will display Success. For a single test item, it takes about
a few seconds or minutes.
Before testing, make sure that the inverter is connected to the grid. Click Test Report to
view the test results of all items.
======Self Test======
>All Test
Test Report
Ovp (59.S2) test
Setting GMPPT
You can set the shadow tracking speed with four options, which are Off, Low, Middle, and
High. This function is off by default.
• Off: Switch off the shadow tracking function.
• Low: Scan the shadow every four hours.
• Middle: Scan the shadow every three hours.
• High: Scan the shadow per hour.
=======GMPPT=======
PV1 Control
> Low <
Setting Modbus
You can set the address and select the braud rate of the external communication protocol
for communicating with external equipment.
======Modbus======
Braud Rate
> 9600 <
======Modbus======
>Address
1
